Boost Your Output: Press 35 Boards at Once
Our factory makes the Electric Hot Press for Plywood for big board makers. This machine can press 35 boards in one go. This gives you over 1,000 boards every day. One of our clients in Southeast Asia makes 8,000 sheets daily. They saw their output go up fast after using this press. Their workers also feel less tired. The Electric Hot Press for Plywood raised their single-shift output by three times. It also worked for six months with no stop. We have built machines for 26 years. This model is our best for big jobs.
Get Strong and Flat Boards Every Time
This press gives every board the same heat and pressure. Your plywood will have a glue strength above 1.2MPa. That is a lot higher than most brands need. You will not see bubbles or warps on your boards. Our heat plates use strong Q355B steel. The plate is very flat with a tolerance of just ±0.1mm. This means all your boards will look and feel the same. Your brand will get a good name for quality. We use a fully automatic system. The Electric Hot Press for Plywood saves you up to 80% on labor costs.
Run on Auto and Save on Labor
High labor cost is a big worry. We made this machine to fix that. It has a Mitsubishi PLC and a touch screen. You just set the numbers. Then the machine loads, presses, holds, and unloads by itself. One worker can run many machines. The machine also has a self-check tool. If something goes wrong, the screen shows the problem. It also has overload and overheat alarms. One of our long-time clients said their down time fell by 90% after using our press. Below are the key facts for this model.
|
Parameter |
Value |
|
Rated Pressure |
800T |
|
Main Cylinder |
Ø320*4 pcs, Lift Cylinder Ø180*2 pcs |
|
Platen Size |
2700mm1370mm42mm (Custom 4x9ft, 5x10ft) |
|
Platen Material |
Q355B Steel |
|
Distance Between Platens |
75mm |
|
Closing Time |
25 seconds |
|
Hot Press Cycle |
3-8 minutes per cycle |
|
Control Type |
PLC Full Auto with Touch Screen |
|
Total Motor Power |
101KW |
|
Clamping Plate Material |
Low-Alloy Steel |
|
Heating Method |
Thermal Oil or Steam |
We give you on-site setup and full training. The main parts are made to last over 20 years. Let us use our experience to help your business. Contact us for your auto hot press solution.
