Tilted Rollers Stop Waves and Bounce Marks
Standard sanders leave marks. Waves. Bounce marks. Sand lines. These show up after you paint or laminate. Our Professional Sanding Machine fixes this problem. The sanding roller is tilted at 5 to 8 degrees. This changes how the sandpaper hits the wood. It cuts at an angle. No waves. No bounce marks. A plywood factory that ships to Japan used this machine. The Japanese buyer had very high standards. The old sander got them rejected. After switching to our machine, their surface quality went up two levels. Rejects went to zero.
Heavy Frame for Steady Work
Sanding makes vibration. Vibration causes marks. The Professional Sanding Machine has a heavy welded frame. The sanding head is made from cast steel. This absorbs vibration. The machine stays steady even at full load. The main motor is 55KW or 75KW. You choose the power you need. The feed motor is 7.5KW with variable speed. You can run the belt at 10 to 50 meters per minute. The sanding belt is 2720mm by 1330mm. The sanding roller is Ø400mm.
Smart Control for Easy Operation
The machine has a PLC and a touch screen. You set the thickness. You set the belt tension. You set the belt tracking. The machine does the rest. The feed system uses a strong belt. It holds the board tight. No slipping. No stopping. The machine has safety guards and a dust port. Connect it to your dust collector. Your shop stays clean. Here are the specs.
|
Parameter |
Value |
|
Max Working Width |
1300mm (custom available) |
|
Thickness Range |
3 to 40mm |
|
Sanding Belt Size |
2720*1330mm |
|
Sanding Roller Size |
Ø400*1365mm (Low alloy steel) |
|
Main Motor Power |
55kW or 75kW (optional) |
|
Feed Motor Power |
7.5kw variable speed |
|
Feed Speed |
10 to 50 m/min |
|
Belt Speed |
20 to 30 m/s |
|
Machine Weight |
About 7 to 8 tons |
We give you one-stop setup and training. This machine lasts 10 to 20 years. Choose us for a wave-free, mark-free surface.
