Air Control for Precise Glue on Big Boards
Glue amount changes with glue type. Thin glue needs different pressure than thick glue. The Pneumatic Double Face Gluing Machine lets you adjust with air. You turn a valve. Air pressure pushes the rollers together. More air means more pressure. Less air means less pressure. This changes how much glue goes on your board. You can do it while the machine runs. No stopping. No waste. The machine works with water glue, white glue, and oil glue. It works for single side or double side gluing.
Rollers Separate Fast When Something Goes Wrong
Debris happens. A piece of hard material can get into your rollers. On old machines, this damages the rollers. The Pneumatic Double Face Gluing Machine has a quick release. You push a valve. Air pushes the rollers apart in one second. The debris falls out. Your rollers stay like new. No repair cost. No down time. This feature alone can save you thousands of dollars over the life of the machine.
Quiet Gears and a Strong Frame
The machine uses a gear drive system. Gears are quieter than chains. They also last longer. The rubber rollers are Ø420mm. The glue rollers are Ø292mm. Both are chrome plated. Glue does not stick. The frame is thick steel plate. No shaking. The control box has start, stop, and speed buttons. One worker runs the whole operation. The roller layout is front and back. Board goes in from the front. Top gets glue. Board moves forward. Bottom gets glue. One pass. Both sides done. Here are the specs.
|
Parameter |
Value |
|
Rubber Roller Size |
Ø420*2700mm (Natural rubber, 50 hardness) |
|
Glue Roller Size |
Ø292*2700mm (Chrome plated alloy) |
|
Roller Arrangement |
Front and back |
|
Glue Type |
Single side or double side |
|
Motor Power |
5.5KW (upgrade to variable speed) |
|
Machine Weight |
About 4500kg |
|
Machine Size |
4365mm1390mm1870mm |
We have 26 years of experience. We set up your machine and train your workers. This gluer gives you width, precision, and speed. Contact us to bring smart gluing to your shop.
