Air Power Controls Your Glue Amount
Getting the right amount of glue on a big board is hard. Too little and the bond fails. Too much and you waste money. The Pneumatic Double Side Gluing Machine uses air pressure to control the glue. You turn a valve. Air pushes the rollers together with more or less force. This changes how much glue goes on the board. It works for water glue, white glue, and oil glue. You can adjust it while the machine is running. No stopping. No guessing.

Safe Roller Separation Keeps Your Machine Safe
Sometimes a piece of debris gets into the rollers. On normal machines, this can damage the rollers. The Pneumatic Double Side Gluing Machine has a safety feature. You push a valve. Air pressure pushes the rollers apart. The debris falls out. No damage to your rollers. No down time for repairs. This is a big deal for busy shops. One accident can cost you hours of lost production. This feature stops that from happening.

Big Rollers for Even Coverage
The rubber rollers are Ø420mm. That is big. Big rollers give you more even glue coverage. The glue rollers are Ø292mm. Both are chrome plated. Glide does not stick. The machine uses gears to drive the rollers. The drive is quiet and smooth. The frame is thick steel plate. No shaking. The control box has start, stop, and speed control. Here are the specs.

|
Parameter |
Value |
|
Rubber Roller Size |
Ø420*2700mm (Natural rubber, 50 hardness) |
|
Glue Roller Size |
Ø292*2700mm (Chrome plated alloy) |
|
Roller Arrangement |
Top and bottom |
|
Glue Type |
Single side or double side |
|
Motor Power |
5.5KW (upgrade to variable speed) |
|
Machine Weight |
About 4500kg |
|
Machine Size |
4365mm1100mm1870mm |
We set up your machine and train your team. This machine has three big features. Wide width. High precision. Fast speed. Not many gluers have all three. Contact us to build your smart production line.
