Same Great Feeder. Different Direction.
Our longitudinal feeder works from the long side of the board. But some machines need boards fed from the short side. Our Transverse Board Feeding Suction Frame is for those lines. The suction cups pick up the board. The arm moves sideways. The board goes onto the feed belt from the short end. A plywood factory had a tight shop layout. Their glue machine fed from the short side. A longitudinal feeder would need a turn table. Our transverse feeder went right in line. No turn table needed. No extra space used.

Six Small Cups for Better Grip
The Transverse Board Feeding Suction Frame uses six small cups. Each is Ø150mm. More cups mean better grip. The cups spread out. They hold the board flat. No sagging. The arm moves on linear rails. Air cylinders move it fast. The PLC controls the timing. You set the board size. The machine adjusts. Feed speed is 6 to 10 boards per minute. Board thickness from 9mm to 30mm.

Built the Same Strong Way
The frame is thick steel. Cable chain protects hoses and wires. Safety sensors stop the machine if a board is missed. The feed belt motor is 0.75KW. You can connect the feeder to your machine PLC. Then the feeder and your machine work together. Here are the specs.

|
Parameter |
Value |
|
Feed Motor Power |
0.75KW |
|
Voltage |
380V/50Hz (other voltages available) |
|
Board Thickness |
9 to 30mm |
|
Suction Cup Size |
Ø150mm x 6 pcs |
|
Feed Speed |
6 to 10 boards per minute |
|
Feed Direction |
Transverse (sideways) |
We set up the feeder and train your workers. This machine replaces 2 to 3 workers. It raises line output by 30%. Choose us for auto feeding from the short side.
